Table of attributes
662
Lenze · 9400 function library · Reference manual · DMS 6.7 EN · 08/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C05154
Measured cycle
19421
4BDD
S
1
INTEGER_32
10000
C05155
TP set position at the input
19420
4BDC
S
1
INTEGER_32
10000
C05010
VMaster: Operating mode
19565
4C6D
S
1
UNSIGNED_32
1
C05011
Target position
19564
4C6C
S
1
INTEGER_32
10000
C05012
Starting position
19563
4C6B
S
1
INTEGER_32
10000
C05013
Master speed
19562
4C6A
A
2
INTEGER_32
10000
C05014
Inching: Speed
19561
4C69
A
2
INTEGER_32
10000
C05015
VMaster: Ramps
19560
4C68
A
3
INTEGER_32
1000
C05016
Unit
19559
4C67
A
2
VISIBLE_STRING
1
C05017
Reference speed
19558
4C66
S
1
INTEGER_32
10000
C05024
Status
19551
4C5F
S
1
INTEGER_32
1
C05025
Master position in the target
19550
4C5E
S
1
UNSIGNED_8
1
C05026
Cycle
19549
4C5D
S
1
INTEGER_32
10000
C05027
Master position at the output
19548
4C5C
S
1
INTEGER_32
10000
C05028
External master position at the input
19547
4C5B
S
1
INTEGER_32
10000
C05100
VMaster: Operating mode
19475
4C13
S
1
UNSIGNED_32
1
C05101
Speed unit
19474
4C12
S
1
VISIBLE_STRING
1
C05102
Reference speed
19473
4C11
S
1
INTEGER_32
10000
C05103
Master speed
19472
4C10
A
2
INTEGER_32
10000
C05104
Inching: Speed
19471
4C0F
A
2
INTEGER_32
10000
C05105
VMaster: Ramps
19470
4C0E
A
3
UNSIGNED_32
1000
C05114
Status
19461
4C05
S
1
INTEGER_32
1
C05117
Speed at the output
19458
4C02
S
1
INTEGER_32
10000
C05118
External speed at the input
19457
4C01
S
1
INTEGER_32
10000
C04700
Teaching
19875
4DA3
A
4
UNSIGNED_8
1
C04701
Table: Position x
19874
4DA2
A
75
INTEGER_32
10000
C04702
Table: Speed x
19873
4DA1
A
50
INTEGER_32
10000
C04703
Table: Acceleration x
19872
4DA0
A
50
INTEGER_32
10000
C04704
Table: S-ramp time x
19871
4D9F
A
50
INTEGER_32
1000
C04705
DIS:bPosTeach
19870
4D9E
A
4
UNSIGNED_8
1
C04706
Table position
19869
4D9D
A
5
UNSIGNED_32
1
C04707
DIS:dnTeachPos
19868
4D9C
A
4
INTEGER_32
10000
C04708
DIS: dnState
19867
4D9B
S
1
INTEGER_32
1
C04709
Position unit
19866
4D9A
A
3
VISIBLE_STRING
1
C04710
Positioning mode
19865
4D99
A
75
UNSIGNED_16
1
C04711
Position profile n = table pos.
19864
4D98
A
75
UNSIGNED_16
1
C04712
Speed profile n = table pos.
19863
4D97
A
75
UNSIGNED_16
1
C04713
Accel. profile n = table pos.
19862
4D96
A
75
UNSIGNED_16
1
C04714
Decel. profile n = table pos.
19861
4D95
A
75
UNSIGNED_16
1
C04715
S-ramp time profile n = table pos.
19860
4D94
A
75
UNSIGNED_16
1
C04716
Final speed profile n = table pos.
19859
4D93
A
75
UNSIGNED_16
1
C04717
Starting pos. TP profile n = table pos.
19858
4D92
A
75
UNSIGNED_16
1
C04718
End pos. TP profile n = table pos.
19857
4D91
A
75
UNSIGNED_16
1
C04719
Sequence profile for profile n with TP
19856
4D90
A
75
UNSIGNED_16
1
C04720
Sequence profile for profile n without
TP
19855
4D8F
A
75
UNSIGNED_16
1
C04721
TP evaluation for profile n
19854
4D8E
A
75
UNSIGNED_32
1
C04723
S-ramp mode
19852
4D8C
A
75
UNSIGNED_16
1
