5.98 L_LdSyncOperation - master value connection
366
Lenze · 9400 function library · Reference manual · DMS 6.7 EN · 08/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Parameter
bXZeroPos
BOOL
Status signal: "Cycle zero crossing in the modulo cycle of the master measuring sys-
tem"
FALSE Cycle zero crossing did not occur:
The resulting dnXActPos_p master position is non-zero, the resulting
master value is in the x modulo cycle.
TRUE Cycle zero crossing occurred:
• The bXZeroPos output is statically set to TRUE if the resulting
dnXActPos_p master position is zero.
• The bXZeroPos output is set to TRUE for one task cycle if the resul-
ting dnXActPos_p master position performs a step change to the
following x modulo cycle (dnXSpeedOut_s > 0: x
max
 0) or to the
previous x modulo cycle (dnXSpeedOut_s < 0: 0  x
max
).
Parameter Possible settings Information
C05090 Coupling measuring systems X and Y
0 Coupling via feed constants One of the units of the master
measuring system is mapped to one
of the units of the slave measuring
system (Lenze setting).
1 Coupling via cycles One of the cycles of the master
measuring system is mapped to one
of the cycles of the slave measuring
system.
2 Free coupling Synchronism depends on the ratio
between the gearbox factors of the
master drive/slave drive and on the
coupling factors, C05092/1 and
C05092/2.
C05091/1 String of digits User-defined unit X
• Display of the unit of the master
measuring system.
C05091/2 String of digits User-defined unit Y
• Display of the unit of the slave
measuring system.
C05092/1 0.0000 214748.3647 Coupling factor x (master measuring
system)
• The value entered here is included
in the resulting synchronism fac-
tor as the denominator term.
• Initialisation: 0.0000
C05092/2 0.0000 214748.3647 Coupling factor y (slave measuring
system)
• The value entered here is included
in the resulting synchronism fac-
tor as the numerator term.
• Initialisation: 0.0000
C05093/1 0 Unit 2147483647 Cycle X
• Display of the cycle of the master
measuring system
C05093/2 0 Unit 2147483647 Cycle Y
• Display of the cycle of the slave
measuring system
Identifier/data type Value/meaning
