5 Function blocks
5.10 L_CamStretchFeed - stretching/compressing the position (relative)
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
5.10.1 Typical application
By means of this FB a feed motion with regard to the feed length at the L_CamProfiler FB can be sim-
ply altered via factors. Like this, the motion profile can be maintained.
[5-21] Example: Material feed with subsequent cut
 Feed motion
 Cutter
M
 Œ
