9400 HighLine | Parameter setting & configuration
Parameter reference
Attribute table
C02703 Max. speed 21872 5570 E 1 INTEGER_32 10000 ; ;
C02704 Max. speed [rpm] 21871 556F E 1 INTEGER_32 10 ;
C02705 Max. acceleration 21870 556E E 1 INTEGER_32 10000 ; ;
C02706 Min. S-ramp time 21869 556D E 1 UNSIGNED_32 1 ; ;
C02707 Permissible direction of rotation 21868 556C E 1 UNSIGNED_32 1 ; ;
C02708 Limited speed 21867 556B A 4 INTEGER_32 10000 ; ;
C02709 Limited speed 21866 556 A A 4 INTEGER_32 10 ;
C02710 Delay lim. speed 21865 5569 A 4 UNSIGNED_32 10000 ; ;
C02711 S-ramp time lim. speed 21864 5568 A 4 UNSIGNED_32 1 ; ;
C02712 Decel. time lim. speed 21863 5567 A 4 UNSIGNED_32 1 ;
C02713 Max. Strecke Handfahren 21862 5566 E 1 UNSIGNED_32 10000 ; ;
C02714 Max. Strecke Handfahren 21861 5565 E 1 UNSIGNED_32 1 ;
C02715 Limitation active 21860 5564 E 1 UNSIGNED_32 1 ;
C02716 Resp. to limitation 21859 5563 A 3 UNSIGNED_32 1 ; ;
C02717 LIM_dwControl 21858 5562 E 1 UNSIGNED_32 1 ;
C02718 LIM_dnState 21857 5561 E 1 INTEGER_32 1 ;
C02719 Limiter: Dig. signals 21856 5560 A 3 UNSIGNED_32 1 ;
C02730 AINx: Gain 21845 5555 A 2 INTEGER_32 100 ; ;
C02731 AINx: Offset 21844 5554 A 2 INTEGER_32 100 ; ;
C02732 AINx: Dead band 21843 5553 A 2 INTEGER_32 100 ; ;
C02733 AOUTx: Gain 21842 5552 A 2 INTEGER_32 100 ; ;
C02734 AOUTx: Offset 21841 5551 A 2 INTEGER_32 100 ; ;
C02800 AINx: Input signal 21775 550F A 2 INTEGER_16 1 ;
C02801 AOUTx: Output signal 21774 550E A 2 INTEGER_16 1 ;
C02802 Status word dig. outputs 21773 550D E 1 BITFIELD_32 1 ;
C02803 Status word dig. inputs 21772 550C E 1 BITFIELD_32 1 ;
C02810 Delay time for TPx 21765 5505 A 10 UNSIGNED_32 1 ; ;
C02830 DIx delay time 21745 54F1 A 8 UNSIGNED_8 1 ; ;
C02853 Vp Lss sat. characteristic 21722 54DA A 17 UNSIGNED_16 1 ; ; ;
C02855 Imax Lss saturat. characteristic 21720 54D8 E 1 UNSIGNED_32 10 ; ; ;
C02859 Lss sat. characteristic 21716 54D4 E 1 UNSIGNED_8 1 ; ; ;
C02860 Rr adjustment 21715 54D3 E 1 UNSIGNED_32 100 ; ;
C02861 Lh adaptation 21714 54D2 E 1 UNSIGNED_32 100 ; ;
Code Name Index Data Access
dec hex DS DA DT Factor R W CINH
