Lenze E94AxHE Servo Drives 9400 HighLine (Firmware 01-37) - Manual (Page 605)

L
Firmware 1.37 - 09/2006 605
9400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C00812
C00812
C00813
C00814
C00815
C00816
C00817
Parameter | Name:
C00812 | MCTRL_dnMotorPosRefValue
Data type: UNSIGNED_32
Index: 23763
d
= 5CD3
h
Internal motor control (MCTRL) signal
Display range
(min. value | unit | max. value)
0 Incr. 4294967295
Subcodes Information
C00812/1 Low Word
C00812/2 High Word
; Read access Write access CINH PLC STOP No transfer COM MOT
Parameter | Name:
C00813 | MCTRL_dnLoadPosRefValue
Data type: UNSIGNED_32
Index: 23762
d
= 5CD2
h
Internal motor control (MCTRL) signal
Display range
(min. value | unit | max. value)
0 Incr. 4294967295
Subcodes Information
C00813/1 Low Word
C00813/2 High Word
; Read access Write access CINH PLC STOP No transfer COM MOT
Parameter | Name:
C00814 | MCTRL_dnBoost
Data type: INTEGER_32
Index: 23761
d
= 5CD1
h
Internal motor control (MCTRL) signal
Display range
(min. value | unit | max. value)
-1000 V 1000
; Read access Write access CINH PLC STOP No transfer COM MOT
Parameter | Name:
C00815 | MCTRL_dnSpeedCtrlIntegrator
Data type: INTEGER_32
Index: 23760
d
= 5CD0
h
Internal motor control (MCTRL) signal
Display range
(min. value | unit | max. value)
-480000 Nm 480000
; Read access Write access CINH PLC STOP No transfer COM MOT
Parameter | Name:
C00816 | MCTRL_dnFieldWeak
Data type: INTEGER_32
Index: 23759
d
= 5CCF
h
Internal motor control (MCTRL) signal
Display range
(min. value | unit | max. value)
-200.00 % 200.00
; Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 100
Parameter | Name:
C00817 | MCTRL_dnSpeedSet_s
Data type: INTEGER_32
Index: 23758
d
= 5CCE
h
Internal motor control (MCTRL) signal
Display range
(min. value | unit | max. value)
-480000 rpm 480000
; Read access Write access CINH PLC STOP No transfer COM MOT
