9400 HighLine | Parameter setting & configuration
Oscilloscope
Data records
428 Firmware 1.37 - 09/2006
L
M
How to export the data record to a file:
1. Go to Oscilloscope toolbar and click .
• The Save data record dialog box appears.
2. Enter a name in the Name of the data record to be stored input field.
3. Click the Export to file button.
4. Specify the data record to be stored and the filing folder in the Save as dialog box.
5. Click Save.
• The dialog box is closed and the current data record is saved.
14.5.2 Loading/importing a data record
Configurations/data records already stored can be loaded in the oscilloscope any time
again, e.g. for the superposition function.
M
How to load a data record from the project:
1. Go to Oscilloscope toolbar and click .
• The Load data record dialog box appears.
2. Select the data record to be loaded from the Data record list field.
3. Click Open.
• The dialog box is closed and the selected data record is saved.
• If the configuration to be loaded contains variables that are no longer available
in the controller, these variables are automatically removed from the
configuration.
M
How to import a data record from a file:
1. Go to Oscilloscope toolbar and click .
• The Load data record dialog box appears.
2. Click the Import button.
3. Select the file to be imported within the desktop environment from the Open
dialog box.
4. Click Open.
• The dialog box is closed and the selected data record is imported.
• If the configuration to be loaded contains variables that are no longer available
in the controller, these variables are automatically removed from the
configuration.
