9400 HighLine | Parameter setting & configuration
TAs for positioning tasks
TA "Multi-purpose positioning" | Program flow
O
Tip!
Detailed information on homing can be found in chapter "Basic drive functions"
subchapter " Homing ".
(C 164)
Control inputs of the function Signal configuration
Lenze setting Control input (Multiplexer parameters)
Sequencer
Enable Homing
Request homing C03160/1
Sequencer
Activate Homing
Start homing C03160/2
DigIn 2 Home mark C03160/3
FALSE Set home position C03160/4
FALSE Reset home position C03160/5
Zero position Home position C03163
