9400 HighLine | Parameter setting & configuration
Drive interface
Controller commands
58 Firmware 1.37 - 09/2006
L
4.6.7 Activate application
If the memory module contains several applications, you can use this controller command
to activate a different application in the controller.
r After mains switching, the preset application will be loaded into the controller.
r If after mains switching another application than the one preset by Lenze is to be
loaded, it must be activated first and then the application selection must be
saved. Save selected application
M
How to activate a different application:
1. Click the icon to stop the current controller program.
2. Select the number of the application to be activated under
C00005 .
3. Execute the controller command "Activate application" with C00002 = "5".
• The application with the number set in C00005 is activated. If it is started
immediately depends on the automatic start setting selected in C02104 .
4.6.8 Save selected application
After mains switching, the controller always loads the preset application, even if a
different application has been active before.
Use the controller command "Save selected application" to select the active application as
presetting, i.e. the memory module will load this application into the controller after every
mains switching.
r When the controller command is executed, the parameter set is saved automatically.
M
Execute the controller command "Save selected application" with C00002 = "7" to
select the active application as presetting.
Note!
When the application is activated, the corresponding parameter set 1 is loaded
automatically and parameter settings executed before will get lost unless the
parameter set was saved before!
