L
Firmware 1.37 - 09/2006 17
9400 HighLine | Parameter setting & configuration
About this Manual
Terminology used
1.2 Terminology used
Term Meaning
»Engineer« Lenze software which supports you throughout the whole machine life
cycle - from planning to maintenance.
Code "Container" for one or several parameters used for controller parameter
setting or monitoring.
Subcode If a code contains several parameters, the individual parameters are
stored under "subcodes".
This Manual uses a slash "/" as a separator between code and subcode
(e.g. "C00118/3").
Function block editor Graphical interconnection tool which is provided for controllers in the
MotionControl HighLevel and TopLevel license level in the »Engineer« on
the FB editor tab and by means of which the technology applications
supplied can also be reconfigured and extended by individual functions.
Function block A function block (FB) can be compared with an integrated circuit that
contains a certain control logic and delivers one or several values when
being executed.
• An entity (reproduction, copy) of the function block is always inserted
in the circuit.
• It is also possible to insert several instances of a function block in a
circuit.
• Each entity has an unequivocal identifier (the entity name) and a
processing number which defines the position the function block is
calculated during the task cycle.
System block System blocks provide interfaces for basic functions and hardware of the
controller in the function block editor of the »Engineer« (e.g. to the
digital inputs).
• System blocks cannot be instanced in contrast to function blocks.
DIS code Parameter that displays the current status or value of an input/output of
a system block.
TA Abbreviation for "Technology Application".
Technology applications are applications prepared by Lenze which form
the basis of solving typical applications.
