Lenze E94AxHE Servo Drives 9400 HighLine (Firmware 01-37) - Manual (Page 549)

L
Firmware 1.37 - 09/2006 549
9400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C00055
C00055
C00056
C00057
C00058
C00059
C00060
Parameter | Name:
C00055 | Phase currents
Data type: INTEGER_32
Index: 24520
d
= 5FC8
h
Display range (min. value | unit | max. value)
-500.00 A 500.00
Subcodes Information
C00055/1 Zero phase-sequence system
C00055/2 Phase U
C00055/3 Phase V
C00055/4 Phase W
; Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 100
Parameter | Name:
C00056 | Torque setpoint
Data type: INTEGER_32
Index: 24519
d
= 5FC7
h
Display range (min. value | unit | max. value)
-21474836.47 Nm 21474836.47
; Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 100
Parameter | Name:
C00057 | Torque
Data type: UNSIGNED_32
Index: 24518
d
= 5FC6
h
Display range (min. value | unit | max. value)
0.000 Nm 2147483.647
Subcodes Information
C00057/1 Maximum torque
C00057/2 Torque at maximum current ( C00022 )
; Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 1000
Parameter | Name:
C00058 | Rotor displacement angle
Data type: INTEGER_32
Index: 24517
d
= 5FC5
h
Setting range (min. value | unit | max. value)
-179.9 ° 179.9
Subcodes Lenze setting Information
C00058/1 -90.0 ° Rotor displ. angle resolver
C00058/2 0.0 ° Rotor displ. angle encoder
C00058/3 0.0 ° Rotor displ. angle module
; Read access ; Write access CINH PLC STOP No transfer COM ; MOT Scaling factor: 10
Parameter | Name:
C00059 | Motor - pole pair number
Data type: UNSIGNED_32
Index: 24516
d
= 5FC4
h
Display range (min. value | unit | max. value)
0 200
; Read access Write access CINH PLC STOP No transfer COM MOT
Parameter | Name:
C00060 | Rotor position
Data type: INTEGER_32
Index: 24515
d
= 5FC3
h
Display range (min. value | unit | max. value)
0 2047
; Read access Write access CINH PLC STOP No transfer COM MOT
