9400 HighLine | Parameter setting & configuration
Technology applications (TAs)
Commissioning using the »Engineer«
240 Firmware 1.37 - 09/2006
L
10.2.4 Networking via standardised ports
For the implementation of different control concepts each technology application has
predefined ports:
O
Tip!
The exact assignment of the ports can be found in the description of the
technology application.
Input ports Output ports Use
LPortAxisIn1 LPortAxisOut1 For the connection of several axes ("horizontal communication")
LPortControl1 LPortStatus1 For the connection with a master control ("vertical communication")
LPortControl2 LPortStatus2
LPort32In1 LPort32Out1 For additional 32 bit process signals
LPort32In2 LPort32Out2
LPort32In3 LPort32Out3
LPort16In1 LPort16Out1 For additional 16 bit process signals
LPort16In2 LPort16Out2
LPort16In3 LPort16Out3
Note!
The TA variants for the 9400 HighLine have the ports predefined with the
"automatic" interface.
After the addition of a network and interconnection of the ports inside the
machine applications the "automatic" interface is specified according to the bus
system used during the device update.
For commissioning of the communication the »Engineer« is required.
