9400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C00773
600 Firmware 1.37 - 09/2006
L
C00773
C00774
C00775
C00776
C00777
C00778
Parameter | Name:
C00773 | MCTRL_dnLoadSpeedAct
Data type: INTEGER_32
Index: 23802
d
= 5CFA
h
Internal motor control (MCTRL) signal
Display range
(min. value | unit | max. value)
-480000 rpm 480000
; Read access Write access CINH PLC STOP No transfer COM MOT
Parameter | Name:
C00774 | MCTRL_dnTorqueAct
Data type: INTEGER_32
Index: 23801
d
= 5CF9
h
Internal motor control (MCTRL) signal
Display range
(min. value | unit | max. value)
-21474836.47 Nm 21474836.47
; Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 100
Parameter | Name:
C00775 | MCTRL_dnOutputSpeedCtrl
Data type: INTEGER_32
Index: 23800
d
= 5CF8
h
Internal motor control (MCTRL) signal
Display range
(min. value | unit | max. value)
-21474836.47 Nm 21474836.47
; Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 100
Parameter | Name:
C00776 | MCTRL_dnInputJerkCtrl
Data type: INTEGER_32
Index: 23799
d
= 5CF7
h
Internal motor control (MCTRL) signal
Display range
(min. value | unit | max. value)
-21474836.47 Nm 21474836.47
; Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 100
Parameter | Name:
C00777 | MCTRL_dnInputTorqueCtrl
Data type: INTEGER_32
Index: 23798
d
= 5CF6
h
Internal motor control (MCTRL) signal
Display range
(min. value | unit | max. value)
-21474836.47 Nm 21474836.47
; Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 100
Parameter | Name:
C00778 | MCTRL_dnFluxAct
Data type: INTEGER_32
Index: 23797
d
= 5CF5
h
Internal motor control (MCTRL) signal
Display range
(min. value | unit | max. value)
-200.00 % 200.00
; Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 100
