L
Firmware 1.37 - 09/2006 539
9400 HighLine | Parameter setting & configuration
Parameter reference
Structure of the parameter descriptions
16.1.3 Parameters with write access
Only parameters with a check mark (;) in front of the "write access" attribute can be
changed by the user. The Lenze setting for these parameters is printed in bold.
r The settings are either selected by means of a selection list or through direct value
entry.
r Values outside the valid setting range are represented in red in the »Engineer«.
16.1.3.1 Parameters with setting range
Description structure
Parameter setting in the »Engineer«
r In the »Engineer«, parameters are set by entering the desired value into the input field
or by means of the arrow buttons:
r Alternatively, the indicated value can be step-by-step increased or reduced by means of
the arrow buttons.
16.1.3.2 Parameters with selection list
Description structure
Parameter setting in the »Engineer«
r In the »Engineer«, a list field is used for parameter setting:
Parameter | Name:
Cxxxxx | _____________
Data type: _______
Index: _______
Description
Setting range
(min. value | unit | max. value) Lenze setting
; Read access ; Write access CINH PLC STOP No transfer COM MOT
Parameter | Name:
Cxxxxx | _____________
Data type: _______
Index: _______
Description
Selection list
(Lenze setting printed in bold)
1
2
3
; Read access ; Write access CINH PLC STOP No transfer COM MOT
