9400 HighLine | Parameter setting & configuration
Diagnostics & error analysis
Error messages of the operating system
CAN module (MXI2): Node guarding error 3 [0x00af0002]
CAN module (MXI2): Node guarding error 4 [0x00af0003]
CAN module (MXI2): Node guarding error 5 [0x00af0004]
CAN module (MXI2): Node guarding error 6 [0x00af0005]
CAN module (MXI2): Node guarding error 7 [0x00af0006]
CAN module (MXI2): Node guarding error 8 [0x00af0007]
Response (Lenze setting printed in bold)
Setting:
C14612/3
(; Adjustable response)
:
None System fault ; Fault ; Trouble ; Quick stop by trouble ; Warning locked ; Warning ; Information
Cause
Remedy
CANopen communication module in MXI2: CAN master
has not received a response to a node guarding telegram
from node 3.
See remedy for "
".
Response (Lenze setting printed in bold)
Setting:
C14612/4
(; Adjustable response)
:
None System fault ; Fault ; Trouble ; Quick stop by trouble ; Warning locked ; Warning ; Information
Cause
Remedy
CANopen communication module in MXI2: CAN master
has not received a response to a node guarding telegram
from node 4.
See remedy for "
".
Response (Lenze setting printed in bold)
Setting:
C14612/5
(; Adjustable response)
:
None System fault ; Fault ; Trouble ; Quick stop by trouble ; Warning locked ; Warning ; Information
Cause
Remedy
CANopen communication module in MXI2: CAN master
has not received a response to a node guarding telegram
from node 5.
See remedy for "
".
Response (Lenze setting printed in bold)
Setting:
C14612/6
(; Adjustable response)
:
None System fault ; Fault ; Trouble ; Quick stop by trouble ; Warning locked ; Warning ; Information
Cause
Remedy
CANopen communication module in MXI2: CAN master
has not received a response to a node guarding telegram
from node 6.
See remedy for "
".
Response (Lenze setting printed in bold)
Setting:
C14612/7
(; Adjustable response)
:
None System fault ; Fault ; Trouble ; Quick stop by trouble ; Warning locked ; Warning ; Information
Cause
Remedy
CANopen communication module in MXI2: CAN master
has not received a response to a node guarding telegram
from node 7.
See remedy for "
".
Response (Lenze setting printed in bold)
Setting:
C14612/8
(; Adjustable response)
:
None System fault ; Fault ; Trouble ; Quick stop by trouble ; Warning locked ; Warning ; Information
Cause
Remedy
CANopen communication module in MXI2: CAN master
has not received a response to a node guarding telegram
from node 8.
See remedy for "
".
