L
Firmware 1.37 - 09/2006 633
9400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C02649
C02649
C02650
C02651
C02652
C02653
C02656
Parameter | Name:
C02649 | Ref. torque limit
Data type: INTEGER_32
Index: 21926
d
= 55A6
h
Basic function " Homing "
Setting range (min. value | unit | max. value) Lenze setting
0.00 % 200.00 10.00 %
; Read access ; Write access CINH PLC STOP No transfer COM MOT Scaling factor: 100
Parameter | Name:
C02650 | Ref. blocking time
Data type: UNSIGNED_32
Index: 21925
d
= 55A5
h
Basic function " Homing "
Setting range (min. value | unit | max. value) Lenze setting
0.000 s 120.000 1.000 s
; Read access ; Write access CINH PLC STOP No transfer COM MOT Scaling factor: 1000
Parameter | Name:
C02651 | Ref. touch probe configuration
Data type: UNSIGNED_32
Index: 21924
d
= 55A4
h
Basic function " Homing "
Setting range (min. value | unit | max. value) Lenze setting
0 4294967295 16
; Read access ; Write access CINH PLC STOP No transfer COM MOT
Parameter | Name:
C02652 | Home pos. after mains switching
Data type: UNSIGNED_32
Index: 21923
d
= 55A3
h
Basic function " Homing "
Selection list (Lenze setting printed in bold)
0 Delete
1 Received
; Read access ; Write access CINH PLC STOP No transfer COM MOT
Parameter | Name:
C02653 | Max. angle of after mains switch.
Data type: INTEGER_32
Index: 21922
d
= 55A2
h
Basic function " Homing "
Setting range (min. value | unit | max. value) Lenze setting
0 ° 1000000 180 °
; Read access ; Write access CINH PLC STOP No transfer COM MOT
Parameter | Name:
C02656 | Current position
Data type: INTEGER_32
Index: 21919
d
= 559F
h
Basic function " Homing "
Display range (min. value | unit | max. value)
-214748.3647 Unit 214748.3647
; Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 10000
