Technology applications (TAs)
Commissioning using the »Engineer«
10.2.2 Parameterise signal combinations
In order to easily change existing signal combinations between the device interfaces and
the application inputs and outputs, parameterisable "multiplexers" are implemented in all
technology applications.
r From a number of signal sources, each multiplexer combines exactly one with a signal
target of the same data type ("combinatorial circuit").
r The signal source is selected by setting the "multiplexer parameter" that is firmly
assigned to the signal target. Each multiplexer parameter always offers a selection of
sensible signal sources only.
r Thus, signal combinations can also be changed (e.g. the assignment of the digital
inputs and outputs) with the keypad only.
O
Tip!
The multiplexer parameters are marked by a prefixed "X" in the name and listed in
the chapter of the corresponding technology application.
Several options are available for changing the signal combinations which are
described in the following sections.
Note!
When you enable the function block editor in the »Engineer» on the FB editor
tab, all multiplexers are removed from the interconnection and the currently set
signal combinations are replaced by fixed signal combinations!
This process is irreversible!
