Page 523
L
Firmware 1.37 - 09/2006
523
9400 HighLine | Parameter setting & configuration
Diagnostics & error analysis
Error messages of the operating system
CAN module (MXI2): Heartbeat error index 28 [0x00ad001b]
CAN module (MXI2): Heartbeat error index 29 [0x00ad001c]
CAN module (MXI2): Heartbeat error index 30 [0x00ad001d]
CAN module (MXI2): Heartbeat error index 31 [0x00ad001e]
CAN module (MXI2): Heartbeat error index 32 [0x00ad001f]
CAN module (MXI2): Life guarding error [0x00ad0020]
Response (Lenze setting printed in bold)
Setting:
C14613/28
(; Adjustable response)
:
None System fault ; Fault ; Trouble ; Quick stop by trouble ; Warning locked ; Warning ; Information
Cause
Remedy
CANopen communication module in MXI2: No heartbeat
telegram received from node 28.
See remedy for "
".
Response (Lenze setting printed in bold)
Setting:
C14613/29
(; Adjustable response)
:
None System fault ; Fault ; Trouble ; Quick stop by trouble ; Warning locked ; Warning ; Information
Cause
Remedy
CANopen communication module in MXI2: No heartbeat
telegram received from node 29.
See remedy for "
".
Response (Lenze setting printed in bold)
Setting:
C14613/30
(; Adjustable response)
:
None System fault ; Fault ; Trouble ; Quick stop by trouble ; Warning locked ; Warning ; Information
Cause
Remedy
CANopen communication module in MXI2: No heartbeat
telegram received from node 30.
See remedy for "
".
Response (Lenze setting printed in bold)
Setting:
C14613/31
(; Adjustable response)
:
None System fault ; Fault ; Trouble ; Quick stop by trouble ; Warning locked ; Warning ; Information
Cause
Remedy
CANopen communication module in MXI2: No heartbeat
telegram received from node 31.
See remedy for "
".
Response (Lenze setting printed in bold)
Setting:
C14613/32
(; Adjustable response)
:
None System fault ; Fault ; Trouble ; Quick stop by trouble ; Warning locked ; Warning ; Information
Cause
Remedy
CANopen communication module in MXI2: No heartbeat
telegram received from node 32.
See remedy for "
".
Response (Lenze setting printed in bold)
Setting:
C14614
(; Adjustable response)
:
None System fault ; Fault ; Trouble ; Quick stop by trouble ; Warning locked ; Warning ; Information
Cause
Remedy
CANopen communication module in MXI2: Cyclic node
monitoring
• Slave response: Maximum time between two node
guarding telegrams (remote transmission request
telegram) from the master has been exceeded.
Select a different life guarding monitoring time or switch
off monitoring.
