9400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C00695
598
Firmware 1.37 - 09/2006
L
C00695
C00696
C00697
C00698
C00730
C00731
C00732
C00733
C00734
C00735
Parameter | Name:
C00695 | Total torque setpoint
Data type: INTEGER_32
Index: 23880
d
= 5D48
h
Display range
(min. value | unit | max. value)
-200.00
%
200.00
;
Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 100
Parameter | Name:
C00696 | Torque setpoint
Data type: INTEGER_32
Index: 23879
d
= 5D47
h
Display range
(min. value | unit | max. value)
-200.00
%
200.00
;
Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 100
Parameter | Name:
C00697 | Filtered torque setpoint
Data type: INTEGER_32
Index: 23878
d
= 5D46
h
Display range
(min. value | unit | max. value)
-200.00
%
200.00
;
Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 100
Parameter | Name:
C00698 | Actual torque
Data type: INTEGER_32
Index: 23877
d
= 5D45
h
Display range
(min. value | unit | max. value)
-200.00
%
200.00
;
Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 100
Parameter | Name:
C00730 | GDO common parameter
Data type: INTEGER_32
Index: 23845
d
= 5D25
h
This code is used internally by the controller and must not be overwritten by the user!
Parameter | Name:
C00731 | GDO channel 1/trigger 1
Data type: INTEGER_32
Index: 23844
d
= 5D24
h
This code is used internally by the controller and must not be overwritten by the user!
Parameter | Name:
C00732 | GDO channel 2/trigger 2
Data type: INTEGER_32
Index: 23843
d
= 5D23
h
This code is used internally by the controller and must not be overwritten by the user!
Parameter | Name:
C00733 | GDO channel 3
Data type: INTEGER_32
Index: 23842
d
= 5D22
h
This code is used internally by the controller and must not be overwritten by the user!
Parameter | Name:
C00734 | GDO channel 4
Data type: INTEGER_32
Index: 23841
d
= 5D21
h
This code is used internally by the controller and must not be overwritten by the user!
Parameter | Name:
C00735 | GDO channel 5
Data type: INTEGER_32
Index: 23840
d
= 5D20
h
This code is used internally by the controller and must not be overwritten by the user!
