L
Firmware 1.37 - 09/2006 561
9400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C00177
C00177
C00178
C00179
C00180
C00181
C00183
Parameter | Name:
C00177 | Service code
Data type: UNSIGNED_32
Index: 24398
d
= 5F4E
h
This code is used internally by the controller and must not be overwritten by the user!
Parameter | Name:
C00178 | Elapsed-time meter
Data type: UNSIGNED_32
Index: 24397
d
= 5F4D
h
Display range (min. value | unit | max. value)
0 s 4294967295
; Read access Write access CINH PLC STOP No transfer COM MOT
Parameter | Name:
C00179 | Power-on time meter
Data type: UNSIGNED_32
Index: 24396
d
= 5F4C
h
Display range (min. value | unit | max. value)
0 s 4294967295
; Read access Write access CINH PLC STOP No transfer COM MOT
Parameter | Name:
C00180 | Service code
Data type: VISIBLE_STRING
Index: 24395
d
= 5F4B
h
For Lenze service only
; Read access ; Write access CINH PLC STOP ; No transfer COM MOT
Parameter | Name:
C00181 | Red. brake chopper threshold
Data type: UNSIGNED_32
Index: 24394
d
= 5F4A
h
Setting range (min. value | unit | max. value) Lenze setting
0 V 100 0 V
; Read access ; Write access CINH PLC STOP No transfer COM MOT
Parameter | Name:
C00183 | Device state
Data type: UNSIGNED_32
Index: 24392
d
= 5F48
h
Display of the device state for controller diagnostics.
Selection list
(display only)
0 Operation
1 Operation/Warning active
2 Operation/warning locked active
3 Operation/Quick stop active
4 Operation/Application stopped
10 Initialisation active
20 System error active
90 Drive switched on
91 Device switched-on/QSP fault
101 Safe torque off active
102 Error active
104 Trouble active
141 Drive ready to start
151 Quick stop by trouble active
; Read access Write access CINH PLC STOP No transfer COM MOT
