9400 HighLine | Parameter setting & configuration
Oscilloscope
Data records
14.5.3 Deleting data record in the project
M
How to delete a data record to be saved in the project:
1. Go to Oscilloscope toolbar and click .
• The Load data record dialog box appears.
2. Click the data record to be deleted with the right mouse key in the Data record list
field to open the Context menu for the data record.
3. Select the Delete data record in the Context menu.
4. Click Abort to close the dialog box again.
14.5.4 Overlay function
The overlay function serves to lay several characteristics from the currently loaded data
records on top of each other, e.g. to compare signal characteristics from different
recordings.
r If two or several data records are loaded in the oscilloscope, e.g. an online data record
and a data record saved before in the project, a "merge" data record is available in the
Data record list field.
r When the merge data record is selected, the desired characteristics can be selected
from the loaded data records in the Vertical channel settings group field which are to
be overlaid or compared.
r If an online data record is used in the merge data record, an update is carried out in the
merge data record in case of a renewed recording.
r Removing variables from an offline or online data record causes the characteristics in
the merge data record to be deleted.
