9400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C02657
634 Firmware 1.37 - 09/2006
L
C02657
C02658
C02659
C02674
C02675
Parameter | Name:
C02657 | HM_dnState
Data type: INTEGER_32
Index: 21918
d
= 559E
h
Status of the basic function " Homing " (LS_Homing).
Display range (min. value | unit | max. value)
-2147483648 2147483647
; Read access Write access CINH PLC STOP No transfer COM MOT
Parameter | Name:
C02658 | HM_dnHomePos_p
Data type: INTEGER_32
Index: 21917
d
= 559D
h
Display of the position signals of the basic function " Homing " (LS_Homing).
Display range (min. value | unit | max. value)
-214748.3647 214748.3647
; Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 10000
Parameter | Name:
C02659 | Homing: Dig. signals
Data type: UNSIGNED_32
Index: 21916
d
= 559C
h
Display of the boolean signals of the basic function " Homing " (LS_Homing).
Selection list
0 FALSE
1 TRUE
Subcodes Information
C02659/1 HM_bEnable
C02659/2 HM_bActivateHoming
C02659/3 HM_bHomingMark
C02659/4 HM_bLoadHomePos
C02659/5 HM_bResetHomePos
C02659/6 HM_bEnabled
C02659/7 HM_bActive
C02659/8 HM_bDone
C02659/9 HM_bHomePosAvailable
; Read access Write access CINH PLC STOP No transfer COM MOT
Parameter | Name:
C02674 | POS_dwActualProfileNumber
Data type: UNSIGNED_32
Index: 21901
d
= 558D
h
Current profile of the basic function " Positioning " (LS_Positioner).
Display range (min. value | unit | max. value)
0 1000
; Read access Write access CINH PLC STOP No transfer COM MOT
Parameter | Name:
C02675 | POS_dnState
Data type: INTEGER_32
Index: 21900
d
= 558C
h
Status of the basic function " Positioning " (LS_Positioner).
Display range (min. value | unit | max. value)
-2147483648 2147483647
; Read access Write access CINH PLC STOP No transfer COM MOT
