L
Firmware 1.37 - 09/2006 637
9400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C02689
C02689
C02692
C02693
C02694
C02695
Parameter | Name:
C02689 | Position follower: Dig. signals
Data type: UNSIGNED_32
Index: 21886
d
= 557E
h
Display of the boolean signals of the basic function " Position follower " (LS_PositionFollower).
Selection list
0 FALSE
1 TRUE
Subcodes Information
C02689/1 PF_bEnable
C02689/2 PF_bEnabled
; Read access Write access CINH PLC STOP No transfer COM MOT
Parameter | Name:
C02692 | SF_dnMotorAcc_x
Data type: INTEGER_32
Index: 21883
d
= 557B
h
Display of the motor acceleration of the basic function " Speed follower " (LS_SpeedFollower).
Display range (min. value | unit | max. value)
-7680000.0 7680000.0
; Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 10
Parameter | Name:
C02693 | SF_dnSpeedAdd_s
Data type: INTEGER_32
Index: 21882
d
= 557A
h
Display of the additive speed setpoint of the basic function " Speed follower " (LS_SpeedFollower).
Display range (min. value | unit | max. value)
-480000.0 rpm 480000.0
; Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 10
Parameter | Name:
C02694 | Speed follower: % signals
Data type: INTEGER_32
Index: 21881
d
= 5579
h
Display of the scaled signals of the basic function " Speed follower " (LS_SpeedFollower).
Display range (min. value | unit | max. value)
-200.00 % 200.00
Subcodes Information
C02694/1 SF_dnSpeedSet_n
C02694/2 SF_dnTorqueAdd_n
; Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 100
Parameter | Name:
C02695 | Speed follower: Dig. signals
Data type: UNSIGNED_32
Index: 21880
d
= 5578
h
Display of the boolean signals of the basic function " Speed follower " (LS_SpeedFollower).
Selection list
0 FALSE
1 TRUE
Subcodes Information
C02695/1 SF_bEnable
C02695/2 SF_bEnabled
; Read access Write access CINH PLC STOP No transfer COM MOT
