Firmware 1.37 - 09/2006 339
9400 HighLine | Parameter setting & configuration
TAs for interconnection via electrical shaft
TA "Synchronism with mark synchronisation" | Machine parameters
O
Tip!
Setting the cycle (C03938) only is required if the selection "Modulo" is set as
traversing range (C02528).
For operation with a virtual master the following setting of the gearbox ratio is
recommended to achieve a good resolution of the guiding angle/master value:
• Numerator (C03930) = 100
• Denominator (C03931) = 1
12.3.3.2 Slave axis (machine axis)
Among other things, the following machine parameters describe the motor end of the
mechanics used.
r Parameter setting: Tab Application parameter Dialog level Overview Synchronism
Machine parameters
O
Tip!
Detailed information for selecting and entering the machine parameters for the
machine axis can be found in the chapter " Drive interface
Machine parameters
(C 35)
Parameters Lenze setting
Value Unit
C00173 Mains - voltage 400/415 V
C00174 Threshold undervoltage (LU) 285 V
C00600 Resp. to DC bus overvoltage Trouble
C02520 Gearbox fact. numer. motor 1
C02521 Gearbox fact. denom. motor 1
C02527 Motor mounting direction Motor rotating CW
C02570 Controller configuration Position control
C02522 Gearbox fact. numer. load 1
C02523 Gearbox fact. denom. load 1
C02529 Mounting direction of position encoder Encoder rotating CW
Description of the mechanics (load, tool)
C02528 Traversing range Modulo
C02524 Feed constant 360.0000 Unit
C02525 Unit °
C02526 User-defined unit °
C02533 Time unit s
C00273/1 Motor moment of inertia Motor-dependent kg cm 2
C00273/2 Load moment of inertia 0.00 kg cm 2
