9400 HighLine | Parameter setting & configuration
Oscilloscope
User interface
420 Firmware 1.37 - 09/2006
L
14.3.6 Trigger/cursor settings
Trigger
Use the Trigger tab to configure the trigger condition.
Selecting the trigger condition
(C 422)
Cursor
If the Cursor tab is on top, you can use a vertical measuring line to read individual
measured values of a selectable channel in the oscilloscope. Using a second vertical
measuring line, it is possible to indicate the difference between two measured values.
Reading individual measured values
(C 426)
14.3.7 Horizontal settings
Use the Horizontal group box to select the time base and the horizontal position.
Selecting the recording time/sample rate
(C 422)
14.3.8 Recording settings
Use the Recording group box to select the sample rate and start recording.
r Since the measured data memory has a limited capacity, a compromise must be found
between the sample rate and the recording time that results from the time base
setting. Selecting the recording time/sample rate
(C 422)
Group box Meaning
Channel Channel selection
Value Display of the value measured at the position of the active measuring line
Difference Display of the difference between the values measured at the two measuring lines
Input field Meaning
Time base [1/Div] Selection of time base
• The current time base setting multiplied by ten results in the recording time.
• Change the time base to stretch or compress measurements that have already been
completed.
Position Selection of the horizontal display position
• The position value can be directly entered into the input field or selected by using the
arrow buttons.
• When the arrow buttons are used and the key is pressed, you can increase the step
width to accelerate the shift.
