L
Firmware 1.37 - 09/2006 629
9400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C02611
C02611
C02612
C02616
C02617
C02619
Parameter | Name:
C02611 | S-ramp time - stop function
Data type: UNSIGNED_32
Index: 21964
d
= 55CC
h
Basic function"Stop "
Setting range (min. value | unit | max. value) Lenze setting
0.000 s 10.000 0.100 s
; Read access ; Write access CINH PLC STOP No transfer COM MOT Scaling factor: 1000
Parameter | Name:
C02612 | Ref. for decel. time - stop
Data type: UNSIGNED_32
Index: 21963
d
= 55CB
h
Basic function"Stop "
Selection list (Lenze setting printed in bold)
0 Reference speed (C00011)
1 Current speed
; Read access ; Write access CINH PLC STOP No transfer COM MOT
Parameter | Name:
C02616 | STP_dnState
Data type: INTEGER_32
Index: 21959
d
= 55C7
h
Status of the basic function " Stop " (LS_Stop).
Display range (min. value | unit | max. value)
-2147483648 2147483647
; Read access Write access CINH PLC STOP No transfer COM MOT
Parameter | Name:
C02617 | STP_bStopActive
Data type: UNSIGNED_32
Index: 21958
d
= 55C6
h
Display of the boolean signals of the basic function " Stop " (LS_Stop).
Selection list (display only)
0 Stop not active
1 Stop active
; Read access Write access CINH PLC STOP No transfer COM MOT
Parameter | Name:
C02619 | Quick stop: Dig. signals
Data type: UNSIGNED_32
Index: 21956
d
= 55C4
h
Display of the boolean signals of the basic function " quick stop " (LS_quick stop).
Selection list
0 FALSE
1 TRUE
Subcodes Information
C02619/1 QSP_bActivate1
C02619/2 QSP_bActivate2
C02619/3 QSP_bActivate3
C02619/4 QSP_bActive
; Read access Write access CINH PLC STOP No transfer COM MOT
