Lenze E94AxHE Servo Drives 9400 HighLine (Firmware 01-37) - Manual (Page 635)

L
Firmware 1.37 - 09/2006 635
9400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C02676
C02676
C02677
C02678
C02679
Parameter | Name:
C02676 | POS_dnProfileSpeed_s
Data type: INTEGER_32
Index: 21899
d
= 558B
h
Display of the max. speed of the current profile of the basic function " Positioning " (LS_Positioner).
Display range (min. value | unit | max. value)
-214748.3647 214748.3647
; Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 10000
Parameter | Name:
C02677 | Positioning: % signals
Data type: INTEGER_32
Index: 21898
d
= 558A
h
Display of the scaled signals of the basic function " Positioning " (LS_Positioner).
Display range (min. value | unit | max. value)
-200.00 % 200.00
Subcodes Information
C02677/1 POS_dnSpeedOverride_n
C02677/2 POS_dnAccOverride_n
; Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 100
Parameter | Name:
C02678 | Positioning: Pos. signals
Data type: INTEGER_32
Index: 21897
d
= 5589
h
Display of the position signals of the basic function " Positioning "(LS_Positioner).
Display range (min. value | unit | max. value)
-214748.3647 214748.3647
Subcodes Information
C02678/1 POS_dnSetPos_p
C02678/2 POS_dnProfileTarget_p
; Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 10000
Parameter | Name:
C02679 | Positioning: Dig. signals
Data type: UNSIGNED_32
Index: 21896
d
= 5588
h
Display of the boolean signals of the basic function " Positioning " (LS_Positioner).
Selection list
0 FALSE
1 TRUE
Subcodes Information
C02679/1 POS_bEnable
C02679/2 POS_bStart
C02679/3 POS_bAbort
C02679/4 POS_bRestart
C02679/5 POS_bEnableOverride
C02679/6 POS_bDisableTP
C02679/7 POS_bEnabled
C02679/8 POS_bActive
C02679/9 POS_bDone
C02679/10 POS_bInTarget
; Read access Write access CINH PLC STOP No transfer COM MOT
