9400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C00854
606 Firmware 1.37 - 09/2006
L
C00854
C00878
C00909
C01120
Parameter | Name:
C00854 | ID status
Data type: UNSIGNED_32
Index: 23721
d
= 5CA9
h
Display range (min. value | unit | max. value)
0 100
; Read access Write access CINH PLC STOP No transfer COM MOT
Parameter | Name:
C00878 | Status DCTRL control input
Data type: UNSIGNED_8
Index: 23697
d
= 5C91
h
Display range
(min. value | unit | max. value)
0 1
Subcodes Information
C00878/1
C00878/2
C00878/3
C00878/4
C00878/5
; Read access Write access CINH PLC STOP No transfer COM MOT
Parameter | Name:
C00909 | Speed limitation
Data type: INTEGER_16
Index: 23666
d
= 5C72
h
Speed limitation for speed setpoint
Setting range
(min. value | unit | max. value)
-175.0 % 175.0
Subcodes Lenze setting Information
C00909/1 175.0 % Upper speed limit value
C00909/2 -175.0 % Lower speed limit value
; Read access ; Write access CINH PLC STOP No transfer COM MOT Scaling factor: 10
Parameter | Name:
C01120 | Sync source
Data type: UNSIGNED_8
Index: 23455
d
= 5B9F
h
Selection list (Lenze setting printed in bold)
0 Off
1 CAN on-board
2 CAN module
4 Module in MXI1
5 Module in MXI2
6 Digital input 1
7 Digital input 2
8 Digital input 3
9 Digital input 4
10 Digital input 5
11 Digital input 6
12 Digital input 7
13 Digital input 8
; Read access ; Write access CINH PLC STOP No transfer COM MOT
