9400 highline | parameter setting & configuration – Lenze E94AxHE Servo Drives 9400 HighLine (Firmware 01-37) User Manual
Page 354
9400 HighLine | Parameter setting & configuration
TAs for interconnection via electrical shaft
TA "Synchronism with mark synchronisation" | "Homing" mode
354
Firmware 1.37 - 09/2006
L
O
Tip!
Detailed information on homing can be found in chapter "Basic drive functions"
subchapter "
Control inputs of the function
Signal configuration
Lenze setting
Control input
(Multiplexer parameters)
FALSE Start homing
C03160/2
DigIn 2 Home mark
C03160/3
C03011 Set home position
C03160/4
C03012 Home position
C03163
FALSE Reset home position
C03160/5
