9400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C02810
C02810
C02830
C02850
C02851
Parameter | Name:
C02810 | Delay time for TPx
Data type: UNSIGNED_32
Index: 21765
d
= 5505
h
The set delay time will be considered when the position is determined at the touch probe time and will be used to
compensate for dead times, if necessary.
• Please observe the setting of the input filter for the digital inputs ( C02830 ).
Setting range (min. value | unit | max. value)
0 us 7000
Subcodes Lenze setting Information
C02810/1 0 us Delay for touch probe 1 ... 8
C02810/...
C02810/10
; Read access ; Write access CINH PLC STOP No transfer COM MOT
Parameter | Name:
C02830 | DIx delay time
Data type: UNSIGNED_8
Index: 21745
d
= 54F1
h
Input filter for digital inputs
• Can be used to filter "spikes" at the digital inputs, if necessary.
• Each digital input is assigned to a subcode.
• Since the filter is a "counting" filter, the indicated times are only approximate values.
Selection list
Information
0 2 μs Filter time
1 4 μs
2 8 μs
3 16 μs
4 32 μs
5 64 μs
6 128 μs
7 256 μs
8 512 μs
9 1024 μs
10 2048 μs
11 4096 μs
12 8192 μs
13 16384 μs
14 32768 μs
Subcodes Lenze setting Information
C02830/1 0: 2 μs Setting of digital input 1 ... 8
C02830/...
C02830/8
; Read access ; Write access CINH PLC STOP No transfer COM MOT
Parameter | Name:
C02850 | Service code
Data type: UNSIGNED_32
Index: 21725
d
= 54DD
h
This code is used internally by the controller and must not be overwritten by the user!
Parameter | Name:
C02851 | Service code
Data type: UNSIGNED_32
Index: 21724
d
= 54DC
h
This code is used internally by the controller and must not be overwritten by the user!
