Page 477: 9400 highline | parameter setting & configuration
L
Firmware 1.37 - 09/2006
477
9400 HighLine | Parameter setting & configuration
Diagnostics & error analysis
Error messages of the operating system
Memory module: File system has been formatted [0x007c0000]
Memory module: File system has been restored [0x007c0001]
Analog input 1: Master current < 4 mA [0x007d0000]
Invalid PLC configuration [0x007d0001]
Communication error between device and device module [0x007f0002]
CAN on board: Bus-off [0x00830000]
Response (Lenze setting printed in bold)
None System fault Fault Trouble Quick stop by trouble Warning locked Warning : Information
Cause
Remedy
File system of the memory module has been formatted. - (Information only)
Response (Lenze setting printed in bold)
None System fault Fault Trouble Quick stop by trouble Warning locked Warning : Information
Cause
Remedy
File system of the memory module has been restored.
- (Information only)
Response (Lenze setting printed in bold)
Setting:
(; Adjustable response)
;
None System fault : Fault ; Trouble ; Quick stop by trouble ; Warning locked ; Warning ; Information
Cause
Remedy
Master current is in the impermissible range -4 ... +4 mA,
e.g. due to a line break or a defective master current
value encoder.
• Only for parameterisation as master current input
(see
Remove open circuit.
Response (Lenze setting printed in bold)
None System fault : Fault Trouble Quick stop by trouble Warning locked Warning Information
Cause
Remedy
An invalid control configuration has occurred.
Load other application.
Response (Lenze setting printed in bold)
Setting:
(; Adjustable response)
:
None System fault ; Fault Trouble ; Quick stop by trouble ; Warning locked ; Warning Information
Cause
Remedy
Communication between controller and extension
module is interrupted, e.g. due to disturbances in the
ambience (EMC), a defective hardware or loose contact.
• This monitoring is designed for safe process data
communication.
• Remove EMC fault.
• Properly connect module.
• Switch the mains or restart controller.
• Exchange module/controller.
• Please contact Lenze, if the problem occurs again.
Response (Lenze setting printed in bold)
Setting:
(; Adjustable response)
:
None System fault ; Fault ; Trouble ; Quick stop by trouble ; Warning locked ; Warning ; Information
Cause
Remedy
CAN on board: "Bus-off" state
• Too many faulty telegrams received.
• Cable defective (e.g. loose contact).
• Two nodes with the same ID.
• Remove fault (e.g. EMC).
• Remove loose contact, screw down adapter.
• Assign different node IDs.
