9400 HighLine | Parameter setting & configuration
Motor interface
Initial commissioning
5.1 Initial commissioning
An initial commissioning of the motor is required if the motor data in the memory module
of the controller and the »Engineer« project is not suitable for the application.
r The following stepwise instructions can be used as "check list" to adjust the motor
correctly to the controller.
r Detailed information on the individual steps can be found in the following
subchapters:
Worksteps
1. Read out the motor data of the controller or select them via the »Engineer« motor catalog.
• When the motor connected to the motor has an electronic nameplate (ENP), all motor data are
automatically read out of the ENP and a selection from the motor catalog is not required. Read the
motor data out of the controller (C 66)
• If a motor without ENP or an external motor is used, the motor data can be selected via the
»Engineer« motor catalog. Select motor in the »Engineer« motor catalog (C 66)
2. Accept/adapt route data . (C 69)
3. Parameterise motor encoder . (C 70)
When an external motor is operated on the controller:
• Only in case of a synchronous motor: Set rotor displacement angle . (C 71)
• Only in case of unknown motor parameters:
– Optimise the switching performance of the inverter . (C 73)
– Set motor parameters . (C 75)
4. Define currents and speed limits . (C 78)
5. Select switching frequency . (C 79)
6. Optimise current controller . (C 81)
• Required since the controller parameters depend on the maximum switching frequency needed. The
default values of the motor catalog only represent theoretically calculated approximate values.
7. Save parameter set . (C 57)
8. Save »Engineer« project.
