9400 HighLine | Parameter setting & configuration

Parameter reference

Attribute table

650

Firmware 1.37 - 09/2006

L

Max. power brake resistor

24445

5F7D

E

1

INTEGER_32

1

;

;

Therm. capacity brake resistor

24444

5F7C

E

1

INTEGER_32

1

;

;

Max. temp. of brake resistor

24443

5F7B

E

1

INTEGER_32

1

;

;

Autom. restart after power on

24433

5F71

E

1

UNSIGNED_32

1

;

;

Status word 1

24425

5F69

E

1

BITFIELD_16

1

;

Status word 2

24420

5F64

E

1

BITFIELD_16

1

;

Status/Control word MCTRL

24419

5F63

A

2

UNSIGNED_32

1

;

Controller inhibit by (source)

24417

5F61

E

1

BITFIELD_16

1

;

Quick stop by (source)

24416

5F60

E

1

BITFIELD_16

1

;

Error status

24409

5F59

E

1

VISIBLE_STRING

1

;

Error number

24407

5F57

E

1

UNSIGNED_32

1

;

Logbook event filter

24406

5F56

E

1

UNSIGNED_32

1

;

;

Mains - voltage

24402

5F52

E

1

UNSIGNED_8

1

;

;

Threshold undervoltage (LU)

24401

5F51

E

1

UNSIGNED_32

1

;

;

Elapsed hour meter

24397

5F4D

E

1

UNSIGNED_32

1

;

Power-on time meter

24396

5F4C

E

1

UNSIGNED_32

1

;

Service code

24395

5F4B

E

1

VISIBLE_STRING

1

;

;

Red. brake chopper threshold

24394

5F4A

E

1

UNSIGNED_32

1

;

;

Device state

24392

5F48

E

1

UNSIGNED_32

1

;

Threshold mains recovery detect.

24390

5F46

E

1

UNSIGNED_32

1

;

;

ENP: detected motor type

24389

5F45

E

1

VISIBLE_STRING

1

;

ETS: Identified serial number

24388

5F44

E

1

VISIBLE_STRING

1

;

ETS: Status

24387

5F43

E

1

UNSIGNED_8

1

;

Device name

24376

5F38

E

1

VISIBLE_STRING

1

;

;

Firmware product type

24375

5F37

E

1

VISIBLE_STRING

1

;

Firmware - compile date

24374

5F36

E

1

VISIBLE_STRING

1

;

HW product types

24372

5F34

A

9

VISIBLE_STRING

1

;

HW serial number

24371

5F33

A

9

VISIBLE_STRING

1

;

HW descriptions

24370

5F32

A

6

VISIBLE_STRING

1

;

HW manufacturing data

24369

5F31

A

8

VISIBLE_STRING

1

;

HW manufacturer

24367

5F2F

A

6

VISIBLE_STRING

1

;

HW countries of origin

24366

5F2E

A

6

VISIBLE_STRING

1

;

HW versions

24365

5F2D

A

6

VISIBLE_STRING

1

;

Application: Version

24364

5F2C

E

1

VISIBLE_STRING

1

;

Application: Type code

24363

5F2B

E

1

VISIBLE_STRING

1

;

Application: Compiler date

24362

5F2A

E

1

VISIBLE_STRING

1

;

Required safety module

24361

5F29

E

1

UNSIGNED_8

1

;

;

Application: ID number

24357

5F25

E

1

UNSIGNED_32

1

;

Phase controller gain

24321

5F01

E

1

UNSIGNED_32

100

;

;

Freq. current setpoint filter

24305

5EF1

A

2

UNSIGNED_32

10

;

;

Width - current setp. filter

24304

5EF0

A

2

UNSIGNED_32

10

;

;

Depth - current setp. filter

24303

5EEF

A

2

UNSIGNED_32

1

;

;

Moment of inertia

24302

5EEE

A

2

UNSIGNED_32

100

;

;

Max. change in acceleration

24301

5EED

E

1

UNSIGNED_32

10

;

;

Signal source speed setpoint

24300

5EEC

E

1

UNSIGNED_16

1

;

;

Signal source torque setpoint

24299

5EEB

E

1

UNSIGNED_16

1

;

;

Filter time const. DC detection

24295

5EE7

E

1

UNSIGNED_32

10

;

;

CAN TPDO1 mask byte x

24264

5EC8

A

8

BITFIELD_8

1

;

;

CAN TPDO2 mask byte x

24263

5EC7

A

8

BITFIELD_8

1

;

;

CAN TPDO3 mask byte x

24262

5EC6

A

8

BITFIELD_8

1

;

;

CAN TPDO4 mask byte x

24261

5EC5

A

8

BITFIELD_8

1

;

;

Code

Name

Index

Data

Access

dec

hex

DS

DA

DT

Factor

R

W

CINH
