9400 HighLine | Parameter setting & configuration
Diagnostics & error analysis
Error messages of the operating system
450 Firmware 1.37 - 09/2006
L
Memory module is defective or missing [0x00680002]
Safety module is defective or missing [0x00680003]
MXI1: Module changed during operation [0x00680004]
MXI2: Module changed during operation [0x00680005]
Memory module has been removed [0x00680006]
Response (Lenze setting printed in bold)
None System fault : Fault Trouble Quick stop by trouble Warning locked Warning Information
Cause Remedy
Operating system could not identify the memory
module.
Mains switching
• If the error occurs again: Switch off the controller,
remove memory module and plug in again, switch on
the controller again.
• If the error still occurs: Switch off controller and use a
different memory module.
Response (Lenze setting printed in bold)
None : System fault Fault Trouble Quick stop by trouble Warning locked Warning Information
Cause Remedy
Operating system could not identify the safety module. Mains switching
• If the error occurs again: Switch off the controller,
remove safety module and plug in again, switch on
the controller again.
• If the error still occurs: Switch off controller and use a
different safety module.
Response (Lenze setting printed in bold)
None System fault Fault Trouble Quick stop by trouble : Warning locked Warning Information
Cause Remedy
The extension module you have tried to plug into the
module receptacle MXI1 is not "hot plug" capable.
Plug in valid module and restart controller.
• Through mains switching, the system accepts
modules without "hot plug" capability in the
following switch-on phase.
Response (Lenze setting printed in bold)
None System fault Fault Trouble Quick stop by trouble : Warning locked Warning Information
Cause Remedy
The extension module you have tried to plug into the
module receptacle MXI2 is not "hot plug" capable.
Plug in valid module and restart controller.
• Through mains switching, the system accepts
modules without "hot plug" capability in the
following switch-on phase.
Response (Lenze setting printed in bold)
None : System fault Fault Trouble Quick stop by trouble Warning locked Warning Information
Cause Remedy
You have tried to remove or change the memory module
during operation.
Switch off the controller, plug in memory module and
switch on the controller again.
• If the error occurs again, the memory module is
defective and must be replaced.
