Lenze E94AxHE Servo Drives 9400 HighLine (Firmware 01-37) - Manual (Page 504)

9400 HighLine | Parameter setting & configuration
Diagnostics & error analysis
Error messages of the operating system
504 Firmware 1.37 - 09/2006
L
CAN module (MXI1): Heartbeat error index 10 [0x009e0009]
CAN module (MXI1): Heartbeat error index 11 [0x009e000a]
CAN module (MXI1): Heartbeat error index 12 [0x009e000b]
CAN module (MXI1): Heartbeat error index 13 [0x009e000c]
CAN module (MXI1): Heartbeat error index 14 [0x009e000d]
CAN module (MXI1): Heartbeat error index 15 [0x009e000e]
Response (Lenze setting printed in bold) Setting: C13613/10 (; Adjustable response)
: None System fault ; Fault ; Trouble ; Quick stop by trouble ; Warning locked ; Warning ; Information
Cause Remedy
CANopen communication module in MXI1: No heartbeat
telegram received from node 10.
See remedy for " Heartbeat error index 1 ".
Response (Lenze setting printed in bold) Setting: C13613/11 (; Adjustable response)
: None System fault ; Fault ; Trouble ; Quick stop by trouble ; Warning locked ; Warning ; Information
Cause Remedy
CANopen communication module in MXI1: No heartbeat
telegram received from node 11.
See remedy for " Heartbeat error index 1 ".
Response (Lenze setting printed in bold) Setting: C13613/12 (; Adjustable response)
: None System fault ; Fault ; Trouble ; Quick stop by trouble ; Warning locked ; Warning ; Information
Cause Remedy
CANopen communication module in MXI1: No heartbeat
telegram received from node 12.
See remedy for " Heartbeat error index 1 ".
Response (Lenze setting printed in bold) Setting: C13613/13 (; Adjustable response)
: None System fault ; Fault ; Trouble ; Quick stop by trouble ; Warning locked ; Warning ; Information
Cause Remedy
CANopen communication module in MXI1: No heartbeat
telegram received from node 13.
See remedy for " Heartbeat error index 1 ".
Response (Lenze setting printed in bold) Setting: C13613/14 (; Adjustable response)
: None System fault ; Fault ; Trouble ; Quick stop by trouble ; Warning locked ; Warning ; Information
Cause Remedy
CANopen communication module in MXI1: No heartbeat
telegram received from node 14.
See remedy for " Heartbeat error index 1 ".
Response (Lenze setting printed in bold) Setting: C13613/15 (; Adjustable response)
: None System fault ; Fault ; Trouble ; Quick stop by trouble ; Warning locked ; Warning ; Information
Cause Remedy
CANopen communication module in MXI1: No heartbeat
telegram received from node 15.
See remedy for " Heartbeat error index 1 ".
