9400 HighLine | Parameter setting & configuration
Standard TAs
TA "Actuator – torque" | Brake control
282 Firmware 1.37 - 09/2006
L
r Parameter setting: Tab Application parameter Dialog level Overview Brake control
Parameters Lenze setting
Value Unit
C02580 Operating mode - brake Brake control off
C02581 Brake activation threshold 50 rpm
C02582 Brake reaction in case of pulse inhibit Activate the brake immediately
C02583 Status input monitoring Not active
C02585 Brake control polarity Not inverted
C02586 Starting torque 1 0.00 Nm
C02587 Starting torque 2 0.00 Nm
C02588 Source of starting torque Starting torque 1/2
C02589 Brake closing time 100 ms
C02590 Brake opening time 100 ms
C02591 Waiting time - status monit. 100 ms
C02593 Waiting time - brake active. 0.000 s
C02594 Test torque 0.00 Nm
C02595 Permissible angle of rotation 5 °
C02596 Grinding speed 100 rpm
C02597 Accel./decel. time - grinding 1.000 s
C02598 Grinding ON time 0.5 s
C02599 Grinding OFF time 0.5 s
Control/setpoint inputs of the function Signal configuration
Lenze setting Control/setpoint input (Multiplexer parameters)
FALSE Open brake (release) C03165/1
FALSE Activate starting torque 2 C03165/2
FALSE Brake status signal C03165/3
FALSE Activate brake test C03165/4
FALSE Grind brake C03165/5
0 % Additional torque C03166
