9400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C02852
646 Firmware 1.37 - 09/2006
L
C02852
C02853
C02854
C02855
C02856
Parameter | Name:
C02852 | Service code
Data type: UNSIGNED_16
Index: 21723
d
= 54DB
h
This code is used internally by the controller and must not be overwritten by the user!
Parameter | Name:
C02853 | Vp Lss saturat. characteristic
Data type: UNSIGNED_16
Index: 21722
d
= 54DA
h
Setting range (min. value | unit | max. value)
0 % 400
Subcodes Lenze setting Information
C02853/1 100 % Saturation characteristic to correct the leakage
inductance and the current controller parameters.
• The saturation characteristic is displayed by 17 points
which are distributed linearly on the X axis.
• The point 17 represents 100 % of the maximum
motor current in the process ( C02855 ).
• The values to be entered in the subcodes represent
the y values of the grid points 1 ... 17.
Correction of the leakage inductance via saturation
characteristic
C02853/2 100 %
C02853/3 100 %
C02853/4 100 %
C02853/5 100 %
C02853/6 100 %
C02853/7 100 %
C02853/8 100 %
C02853/9 100 %
C02853/10 100 %
C02853/11 100 %
C02853/12 100 %
C02853/13 100 %
C02853/14 100 %
C02853/15 100 %
C02853/16 100 %
C02853/17 100 %
; Read access ; Write access ; CINH PLC STOP No transfer COM ; MOT
Parameter | Name:
C02854 | Service code
Data type: UNSIGNED_32
Index: 21721
d
= 54D9
h
This code is used internally by the controller and must not be overwritten by the user!
Parameter | Name:
C02855 | Imax Lss saturat. characteristic
Data type: UNSIGNED_32
Index: 21720
d
= 54D8
h
Maximum motor current in the process
• Defines the grid point 17 of the saturation characteristic set in C02853 .
Correction of the leakage inductance via saturation characteristic
Setting range (min. value | unit | max. value) Lenze setting
0.0 A 6000.0 5.4 A
; Read access ; Write access ; CINH PLC STOP No transfer COM ; MOT Scaling factor: 10
Parameter | Name:
C02856 | Service code
Data type: VISIBLE_STRING
Index: 21719
d
= 54D7
h
This code is used internally by the controller and must not be overwritten by the user!
