Lenze E94AxHE Servo Drives 9400 HighLine (Firmware 01-37) - Manual (Page 599)

L
Firmware 1.37 - 09/2006 599
9400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C00736
C00736
C00737
C00738
C00739
C00770
C00771
C00772
Parameter | Name:
C00736 | GDO channel 6
Data type: INTEGER_32
Index: 23839
d
= 5D1F
h
This code is used internally by the controller and must not be overwritten by the user!
Parameter | Name:
C00737 | GDO channel 7
Data type: INTEGER_32
Index: 23838
d
= 5D1E
h
This code is used internally by the controller and must not be overwritten by the user!
Parameter | Name:
C00738 | GDO channel 8
Data type: INTEGER_32
Index: 23837
d
= 5D1D
h
This code is used internally by the controller and must not be overwritten by the user!
Parameter | Name:
C00739 | GDO status information
Data type: INTEGER_32
Index: 23836
d
= 5D1C
h
This code is used internally by the controller and must not be overwritten by the user!
Parameter | Name:
C00770 | MCTRL_dnMotorPosAct
Data type: UNSIGNED_32
Index: 23805
d
= 5CFD
h
Internal motor control (MCTRL) signal
Display range
(min. value | unit | max. value)
0 Incr. 4294967295
Subcodes Information
C00770/1 Low Word
C00770/2 High Word
; Read access Write access CINH PLC STOP No transfer COM MOT
Parameter | Name:
C00771 | MCTRL_dnLoadPosAct
Data type: UNSIGNED_32
Index: 23804
d
= 5CFC
h
Internal motor control (MCTRL) signal
Display range
(min. value | unit | max. value)
0 Incr. 4294967295
Subcodes Information
C00771/1 Low Word
C00771/2 High Word
; Read access Write access CINH PLC STOP No transfer COM MOT
Parameter | Name:
C00772 | MCTRL_dnMotorSpeedAct
Data type: INTEGER_32
Index: 23803
d
= 5CFB
h
Internal motor control (MCTRL) signal
Display range
(min. value | unit | max. value)
-480000 rpm 480000
; Read access Write access CINH PLC STOP No transfer COM MOT
