L
Firmware 1.37 - 09/2006
475
9400 HighLine | Parameter setting & configuration
Diagnostics & error analysis
Error messages of the operating system
Failure of motor phase U [0x007b002d]
Failure of motor phase V [0x007b002e]
Failure of motor phase W [0x007b002f]
Electronic nameplate: Data loaded [0x007b0030]
Electronic nameplate: Not found [0x007b0031]
Electronic nameplate: Unknown encoder protocol [0x007b0032]
Response (Lenze setting printed in bold)
Setting:
(; Adjustable response)
:
None System fault ; Fault ; Trouble ; Quick stop by trouble ; Warning locked ; Warning Information
Cause
Remedy
U phase interruption of motor cable.
• Check cabling between controller and motor.
• Check parameter setting (
).
Response (Lenze setting printed in bold)
Setting:
(; Adjustable response)
:
None System fault ; Fault ; Trouble ; Quick stop by trouble ; Warning locked ; Warning Information
Cause
Remedy
V phase interruption of the motor cable.
• Check cabling between controller and motor.
• Check parameter setting (
).
Response (Lenze setting printed in bold)
Setting:
(; Adjustable response)
:
None System fault ; Fault ; Trouble ; Quick stop by trouble ; Warning locked ; Warning Information
Cause
Remedy
W phase interruption of the motor cable.
• Check cabling between controller and motor.
• Check parameter setting (
).
Response (Lenze setting printed in bold)
None System fault Fault Trouble Quick stop by trouble Warning locked Warning : Information
Cause
Remedy
New electronic nameplate (ENP) has been found.
- (Information only)
Response (Lenze setting printed in bold)
None System fault Fault Trouble Quick stop by trouble Warning locked Warning : Information
Cause
Remedy
Electronic nameplate (ENP) is not available.
- (Information only)
Response (Lenze setting printed in bold)
None System fault Fault Trouble Quick stop by trouble Warning locked Warning : Information
Cause
Remedy
The connected motor with feedback is not supported by
the controller firmware.
Check drive dimensioning.
