DFIN (MXI1): Z-/Z track error [0x00990002]
DFIN (MXI1): Enable/lamp control signal error [0x00990003]
DFIN (MXI1): Supply cannot be corrected anymore [0x00990004]
DFOUT (MXI1): Maximum frequency reached [0x00990005]
CAN module (MXI1): Bus-off [0x009d0000]
Response (Lenze setting printed in bold)
Setting:
C13040
(; Adjustable response)
;
None System fault : Fault ; Trouble ; Quick stop by trouble ; Warning locked ; Warning ; Information
Cause
Remedy
Digital frequency extension module in MXI1:
Interruption (open circuit) of the signal cable for track Z.
• Check signal cable for track Z.
• Check encoder.
Response (Lenze setting printed in bold)
Setting:
C13041
(; Adjustable response)
;
None System fault ; Fault ; Trouble ; Quick stop by trouble ; Warning locked : Warning ; Information
Cause
Remedy
Digital frequency extension module in MXI1:
Interruption (open circuit) of the signal cable for the
"Enable" signal or no "Enable" signal available.
• Check signal cable for "Enable" signal.
• Check encoder.
Response (Lenze setting printed in bold)
Setting:
C13042
(; Adjustable response)
;
None System fault ; Fault ; Trouble ; Quick stop by trouble ; Warning locked : Warning ; Information
Cause
Remedy
Digital frequency extension module in MXI1: The
encoder voltage controlled by the digital frequency input
has reached the voltage limit.
Check encoder.
Response (Lenze setting printed in bold)
Setting:
C13080
(; Adjustable response)
;
None System fault ; Fault ; Trouble ; Quick stop by trouble ; Warning locked : Warning ; Information
Cause
Remedy
Digital frequency extension module in MXI1: Limit
frequency at the digital frequency output reached.
• The digital frequency has reached the limit value set
in
C013053
.
Check set limit value.
Response (Lenze setting printed in bold)
Setting:
C13595
(; Adjustable response)
;
None System fault ; Fault ; Trouble ; Quick stop by trouble ; Warning locked ; Warning : Information
Cause
Remedy
CANopen communication module in MXI1: "Bus-off"
state
• Too many faulty telegrams received.
• Cable defective (e.g. loose contact).
• Two nodes with the same ID.
• Remove fault (e.g. EMC).
• Remove loose contact, screw down adapter.
• Assign different node IDs.
