9400 HighLine | Parameter setting & configuration
TAs for interconnection via electrical shaft
TA "Synchronism with mark synchronisation" | Application error messages
366 Firmware 1.37 - 09/2006
L
12.3.14 Application error messages
For the output of application-specific error messages an FB instance ApplicationError of the
function block L_DevApplErr is available in the network.
r Via the 8 boolean inputs up to 8 different application error messages with
parameterisable module ID, error ID and error response can be released by the
application.
r The first four inputs can be connected to the multiplexer parameters with the desired
tripping signals. The next four inputs are firmly connected to the tripping signals of the
application.
r Parameter setting: Tab All parameters
Error message Error-ID Error response
1 Free (configurable via C03060/1) 8001 Error
2 Free (configurable via C03060/2) 8002 Error
3 Free (configurable via C03060/3) 8003 Error
4 Activate Modulo mode 8004 Warning
5 Following error 8005 Warning
6 Drive cannot follow 8006 No reaction
7 Drive system interrupted 8007 Quick stop by trouble
8 Reserved 8008 Warning
Parameters Lenze setting
C03990 Module-ID 999
C03991/1...8 Error ID 1 ... 8 See table above
C03992/1...8 Error response 1 ... 8 See table above
Control inputs of the function Signal configuration
Lenze setting Control input (Multiplexer parameters)
FALSE Application fault 1 C03060/1
FALSE Application fault 2 C03060/2
FALSE Application fault 3 C03060/3
