9400 HighLine | Parameter setting & configuration
TAs for positioning tasks
TA "Multi-purpose positioning" | Limiter
404 Firmware 1.37 - 09/2006
L
O
Tip!
Detailed information on the limiter function can be found in chapter "Basic drive
functions" subchapter " Limiter ".
(C 200)
For manual jog only
C02713 Max. path -manual jog 360.0000 Unit
Limited speed 1 ... 4 (only for homing, positioning, and manual jog)
C02708/1 Limited speed 1 3600.0000 Unit/s
C02710/1 Delay lim. speed 1 0.0100 Unit/s 2
C02711/1 S-ramp time lim. speed 1 100 ms
C02708/2 Limited speed 2 7200.0000 Unit/s
C02710/2 Delay lim. speed 2 0.0100 Unit/s 2
C02711/2 S-ramp time lim. speed 2 100 ms
C02708/3 Limited speed 3 14400.0000 Unit/s
C02710/3 Delay lim. speed 3 0.0100 Unit/s 2
C02711/3 S-ramp time lim. speed 3 100 ms
C02708/4 Limited speed 4 28800.0000 Unit/s
C02710/4 Delay lim. speed 4 0.0100 Unit/s 2
C02711/4 S-ramp time lim. speed 4 100 ms
Control inputs of the function Signal configuration
Lenze setting Control input (Multiplexer parameters)
DigIn 3 Positive limit switch C03150/1
DigIn 4 Negative limit switch C03150/2
Parameters Lenze setting
Value Unit
