L
Firmware 1.37 - 09/2006 19
9400 HighLine | Parameter setting & configuration
Introduction
Parameter setting, configuring or programming?
2 Introduction
The basis of every L-force application is an easy and quick parameter setting of prepared
technology applications and solutions*.
This chapter contains basic information on the runtime software model of
L-force and how
you can establish very easily an online connection between PC and controller for parameter
setting with the »Engineer«.
At the end of this chapter you will find an overview of the different signal types & scalings
which serve to process physical values (e.g. speed or position) within the application.
* In preparation!
2.1 Parameter setting, configuring or programming?
The graded runtime software model of L-force provides a simple and universal solution for
motion and process tasks as well as for complex machine functions.
Runtime software
PLC level Programming*
Freely programmable open and closed
loop control functions*
Technology level Configuring
The HighLevel and TopLevel licenses enable you to
extend the provided technology applications by
individual functions using the graphic function block
editor of the »Engineer«. Here, you can access the
comprehensive function libraries of Lenze which
contain, among other things, process controllers,
arithmetic functions, logic blocks, as well as ramp
generators and integrators.
Parameter setting
The StateLevel license includes a range of technology
which can be put into operation easily with a keypad
or via dialogs in the »Engineer«.
Motion Control TopLevel
Additional motion and process control
modes for complex drive tasks.
Motion Control HighLevel
Individual expansion of the basic
functions & technology applications by
means of function block editor and
comprehensive function library.
Motion Control StateLevel
Parameterisable basic functions &
technology applications.
* In preparation!
