9400 HighLine | Parameter setting & configuration
Basic drive functions
Quick stop | Activating/Deactivating quick stop
154 Firmware 1.37 - 09/2006
L
9.3.2 Activating/Deactivating quick stop
Quick stop through the application is activated/deactivated via the three inputs
QSP_bActivate1...3 of the system block LS_Quickstop .
(C 155)
r The three control inputs are linked via a logic OR gate, i.e. in order to activate quick stop,
only one of the three inputs must be set to TRUE. To deactivate quick stop, though, all
three inputs must be reset to FALSE.
r The control inputs can be linked with terminals (digital inputs) and/or process data in
the function block editor.
Further options for activating quick stop
r Via controller command "Activate quick stop" ( C00002 = "45"), e.g. via a corresponding
SDO of a higher-level control, an HMI or the »Engineer«.
r Via the o key at the keypad, unless the Lenze setting of C00469 (assignment of the
key) has been changed.
r Through the response "quick stop by trouble" parameterised for monitoring.
Note!
In the standard technology applications the control input QSP_bActivate1 is
linked with the digital input DI1 in the Lenze setting.
