Lenze E94AxHE Servo Drives 9400 HighLine (Firmware 01-37) - Manual (Page 585)

L
Firmware 1.37 - 09/2006 585
9400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C00465
C00465
C00466
C00467
C00468
C00469
C00490
Parameter | Name:
C00465 | Keypad: Welcome screen time-out
Data type: UNSIGNED_8
Index: 24110
d
= 5E2E
h
Selection list (Lenze setting printed in bold)
0 Never show welcome screen
5 5 min
15 15 min
30 30 min
60 60 min
; Read access ; Write access CINH PLC STOP No transfer COM MOT
Parameter | Name:
C00466 | Keypad: Default parameters
Data type: UNSIGNED_16
Index: 24109
d
= 5E2D
h
Setting range (min. value | unit | max. value) Lenze setting
0 65535 0
; Read access ; Write access CINH PLC STOP No transfer COM MOT
Parameter | Name:
C00467 | Keypad: Default welcome screen
Data type: UNSIGNED_8
Index: 24108
d
= 5E2C
h
Selection list (Lenze setting printed in bold)
0 Main menu
1 Parameter list
; Read access ; Write access CINH PLC STOP No transfer COM MOT
Parameter | Name:
C00468 | Service code
Data type: UNSIGNED_8
Index: 24107
d
= 5E2B
h
This code is used internally by the controller and must not be overwritten by the user!
Parameter | Name:
C00469 | Keypad: Fct. STOP key
Data type: UNSIGNED_8
Index: 24106
d
= 5E2A
h
Selection list (Lenze setting printed in bold)
0 No function
1 Inhibit controller
2 Activate quick stop
3 Stop application
; Read access ; Write access CINH PLC STOP No transfer COM MOT
Parameter | Name:
C00490 | Position encoder
Data type: UNSIGNED_16
Index: 24085
d
= 5E15
h
Selection list (Lenze setting printed in bold)
0 Resolver X7
1 Encoder X8
2 Encoder module in MXI1
3 Encoder module in MXI2
4 From application
10 Motor encoder
; Read access ; Write access ; CINH PLC STOP No transfer COM ; MOT
