9400 HighLine | Parameter setting & configuration
Oscilloscope
Data records
14.5 Data records
If several data records are loaded in the oscilloscope at the same time, the data record to
be displayed is selected via the list field Data record. There are three types of data records:
Online data record
The online data record is the only data record serving to establish a connection to the
target system. When the online data record has established the connection completely, it
can communicate with the target system.
r In the list field Data record the online data record is marked with a prefixed asterisk (*).
Offline data record
The offline data record is already stored in the project and loaded in the oscilloscope again,
or imported from a file.
Merge data record
The merge data record is automatically available in the list field Data record if two or more
data records are loaded in the oscilloscope at the same time.
r In the merge data record, several characteristics from the currently loaded data records
can be laid on top of each other, e.g. to compare signal characteristics from different
recordings. Overlay function
(C 429)
14.5.1 Saving/exporting a data record
After the variables to be recorded have been selected and the required settings have been
entered, you can save the configuration and recording, if already executed, for future use
in the project or export them to a file.
M
How to save the data record in the project:
1. Go to Oscilloscope toolbar and click .
• The Save data record dialog box appears.
2. Enter a name in the Name of the data record to be stored input field.
3. Click Filing in the project.
• The dialog box is closed and the current data record is filed in the project.
Note!
The data record is only saved if the entire project is saved!
