Lenze E94AxHE Servo Drives 9400 HighLine (Firmware 01-37) - Manual (Page 643)

L
Firmware 1.37 - 09/2006 643
9400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C02730
C02730
C02731
C02732
C02733
C02734
Parameter | Name:
C02730 | AINx: Gain
Data type: INTEGER_32
Index: 21845
d
= 5555
h
Setting range (min. value | unit | max. value)
-200.00 % 200.00
Subcodes Lenze setting Information
C02730/1 100.00 % Gain of analog input 1
C02730/2 100.00 % Gain of analog input 2
; Read access ; Write access CINH PLC STOP No transfer COM MOT Scaling factor: 100
Parameter | Name:
C02731 | AINx: Offset
Data type: INTEGER_32
Index: 21844
d
= 5554
h
Setting range (min. value | unit | max. value)
-200.00 % 200.00
Subcodes Lenze setting Information
C02731/1 0.00 % Offset of analog input 1
C02731/2 0.00 % Offset of analog input 2
; Read access ; Write access CINH PLC STOP No transfer COM MOT Scaling factor: 100
Parameter | Name:
C02732 | AINx: Dead band
Data type: INTEGER_32
Index: 21843
d
= 5553
h
Setting range (min. value | unit | max. value)
0.00 % 100.00
Subcodes Lenze setting Information
C02732/1 0.00 % Dead band of analog input 1
C02732/2 0.00 % Dead band of analog input 2
; Read access ; Write access CINH PLC STOP No transfer COM MOT Scaling factor: 100
Parameter | Name:
C02733 | AOUTx: Gain
Data type: INTEGER_32
Index: 21842
d
= 5552
h
Setting range
(min. value | unit | max. value)
-200.00 % 200.00
Subcodes Lenze setting Information
C02733/1 100.00 % Gain of analog output 1
C02733/2 100.00 % Gain of analog output 2
; Read access ; Write access CINH PLC STOP No transfer COM MOT Scaling factor: 100
Parameter | Name:
C02734 | AOUTx: Offset
Data type: INTEGER_32
Index: 21841
d
= 5551
h
Setting range (min. value | unit | max. value)
-200.00 % 200.00
Subcodes Lenze setting Information
C02734/1 0.00 % Offset of analog output 1
C02734/2 0.00 % Offset of analog output 2
; Read access ; Write access CINH PLC STOP No transfer COM MOT Scaling factor: 100
