9400 HighLine | Parameter setting & configuration
I/O terminals
Analog inputs
118 Firmware 1.37 - 09/2006
L
7.2.2 Parameter setting
Short overview of parameters for the analog inputs:
7.2.3 Reconfiguring analog input 1 as a current input
Proceed as follows to reconfigure analog input 1 as a current input:
1. Bridge terminals A1R and A1 on terminal strip X3 by means of wiring.
2. Select the corresponding current loop under
C00034 .
O
Tip!
In this way, you can implement a 4 ...20 mA current loop, e.g. for speed setpoint
selection.
Open-circuit monitoring
Under
C00598 , you can select an error response to an open circuit for the 4 ...20 mA current loop.
Parameter Information
C00034 Config. analog input 1
C00598 Resp. to open circuit AIN1
C02730/1 AIN1: Gain
C02730/2 AIN2: Gain
C02731/1 AIN1: Offset
C02731/2 AIN2: Offset
C02732/1 AIN1: Dead band
C02732/2 AIN2: Dead band
C02800/1 AIN1: Input signal (-16384 ≡ -100 %, 16383 ≡ 100 %)
C02800/2 AIN2: Input signal (-16384 ≡ -100 %, 16383 ≡ 100 %)
Highlighted in grey = display parameter
