L
Firmware 1.37 - 09/2006
555
9400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C00120
C00120
C00121
C00122
C00123
C00126
C00127
Parameter | Name:
C00120 | Mot. overload protection (I²xt)
Data type: UNSIGNED_32
Index: 24455
d
= 5F87
h
Threshold for I
2
x t disconnection
• Disconnection is carried out if the thermal motor load (
) is higher than the set threshold.
• A 100 % thermal motor load corresponds to a permanently flowing rated motor current
Setting range
(min. value | unit | max. value)
Lenze setting
0
%
200 105 %
;
Read access ; Write access CINH PLC STOP No transfer COM ; MOT
Parameter | Name:
C00121 | Motor temp. warning threshold
Data type: UNSIGNED_32
Index: 24454
d
= 5F86
h
Temperature threshold for motor temperature advance warning
• The reaction for reaching the threshold can be selected in
Setting range
(min. value | unit | max. value)
Lenze setting
0
°C
150 120 °C
;
Read access ; Write access CINH PLC STOP No transfer COM ; MOT
Parameter | Name:
C00122 | Heatsink temp. warn. threshold
Data type: UNSIGNED_32
Index: 24453
d
= 5F85
h
Temperature threshold for heatsink temperature advance warning
• The reaction for reaching the threshold can be selected in
Setting range
(min. value | unit | max. value)
Lenze setting
0
°C
85 85 °C
;
Read access ; Write access CINH PLC STOP No transfer COM MOT
Parameter | Name:
C00123 | Device util. warning threshold
Data type: UNSIGNED_32
Index: 24452
d
= 5F84
h
Adjustable threshold for I x t advance warning
• The advance warning is sent if the controller load (
) is higher than the set threshold.
• The reaction for reaching the threshold can be selected in
Setting range
(min. value | unit | max. value)
Lenze setting
0
%
100 90 %
;
Read access ; Write access CINH PLC STOP No transfer COM MOT
Parameter | Name:
C00126 | CPU temp. warning threshold
Data type: UNSIGNED_32
Index: 24449
d
= 5F81
h
Temperature threshold for advance warning of CPU temperature on the control card
• The reaction for reaching the threshold can be selected in
Setting range
(min. value | unit | max. value)
Lenze setting
0
°C
85 70 °C
;
Read access ; Write access CINH PLC STOP No transfer COM MOT
Parameter | Name:
C00127 | Mot. overload warning threshold
Data type: UNSIGNED_32
Index: 24448
d
= 5F80
h
Adjustable threshold for I
2
x t advance warning
• The advance warning is sent if the thermal motor load (
) is higher than the set threshold.
• The reaction for reaching the threshold can be selected in
Setting range
(min. value | unit | max. value)
Lenze setting
0
%
200 100 %
;
Read access ; Write access CINH PLC STOP No transfer COM ; MOT
