9400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C00443
584
Firmware 1.37 - 09/2006
L
C00443
C00444
Parameter | Name:
C00443 | DIx status
Data type: UNSIGNED_8
Index: 24132
d
= 5E44
h
Display range
(min. value | unit | max. value)
0
1
Subcodes
Information
C00443/1
Digital input 1
C00443/2
Digital input 2
C00443/3
Digital input 3
C00443/4
Digital input 4
C00443/5
Digital input 5
C00443/6
Digital input 6
C00443/7
Digital input 7
C00443/8
Digital input 8
C00443/9
Controller inhibit (inversion of input X5/RFR)
C00443/10
Internal signal
C00443/11
Feedback input of holding brake
C00443/12
State bus input
;
Read access Write access CINH PLC STOP No transfer COM MOT
Parameter | Name:
C00444 | DOx status
Data type: UNSIGNED_8
Index: 24131
d
= 5E43
h
Display range
(min. value | unit | max. value)
0
1
Subcodes
Information
C00444/1
Digital output 1
C00444/2
Digital output 2
C00444/3
Digital output 3
C00444/4
Digital output 4
C00444/5
Internal signal
C00444/6
Internal signal
C00444/7
Internal signal
C00444/8
Internal signal
C00444/9
User LED
C00444/10
Internal signal
C00444/11
Internal signal
C00444/12
Internal signal
C00444/13
Control output of holding brake
C00444/14
Internal signal
C00444/15
Internal signal
C00444/16
Internal signal
C00444/17
Internal signal
C00444/18
State bus output
;
Read access Write access CINH PLC STOP No transfer COM MOT
