9400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C02698
638 Firmware 1.37 - 09/2006
L
C02698
C02699
C02700
C02701
C02702
Parameter | Name:
C02698 | Torque follower: % signals
Data type: INTEGER_32
Index: 21877
d
= 5575
h
Display of the boolean input/output signals of the basic function " Torque follower " (LS_TorqueFollower).
Display range (min. value | unit | max. value)
-200.00 % 200.00
Subcodes Information
C02698/1 TF_TorqueSet_n
C02698/2 TF_dnSpeedHighLimit_n
C02698/3 TF_dnSpeedLowLimit_n
; Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 100
Parameter | Name:
C02699 | Torque follower: Dig. signals
Data type: UNSIGNED_32
Index: 21876
d
= 5574
h
Display of the boolean input/output signals of the basic function " Torque follower " (LS_TorqueFollower).
Selection list
0 FALSE
1 TRUE
Subcodes Information
C02699/1 TF_bEnable
C02699/2 TF_bEnabled
; Read access Write access CINH PLC STOP No transfer COM MOT
Parameter | Name:
C02700 | Software limit pos. effective
Data type: UNSIGNED_32
Index: 21875
d
= 5573
h
Basic function " Limiter "
Selection list (Lenze setting printed in bold)
0 Deactivated
1 Activated
; Read access ; Write access CINH PLC STOP No transfer COM MOT
Parameter | Name:
C02701 | Software limit positions
Data type: INTEGER_32
Index: 21874
d
= 5572
h
Basic function " Limiter "
Setting range (min. value | unit | max. value)
-214748.3647 Unit 214748.3647
Subcodes Lenze setting Information
C02701/1 0.0000 Unit Positive software limit position
C02701/2 0.0000 Unit Negative software limit position
; Read access ; Write access CINH PLC STOP No transfer COM MOT Scaling factor: 10000
Parameter | Name:
C02702 | Limitations effective
Data type: UNSIGNED_32
Index: 21873
d
= 5571
h
Basic function " Limiter "
Selection list
(Lenze setting printed in bold)
0 Deactivated
1 Activated
; Read access ; Write access CINH PLC STOP No transfer COM MOT
